Description
Penny & Giles SRH880P submersible contactless rotary position sensor has been specially developed to meet the harsh operating requirements in heavy-duty industrial position-sensing applications, including construction, agricultural, military and utility vehicles, as well as a variety of uses in steelworks and power generating plants. This model can operate at a submerged depth of 2m (6.5 feet).
Features of the SRH880P Submersible Contactless Rotary Position Sensor:
- Contactless – Hall-effect technology
- Single output channel
- 5Vdc or 9-30Vdc supply
- Total sensor measurement range from 0-20° to 0-360°
- Analogue or Digital (PWM) output
- 12-bit resolution over selected measuring range
- Low noise level (1mVrms) on output signal
- Rugged 88mm housing design, available in aluminium or stainless steel
- Superior shaft strength with double-bearing support
- Operating temperature -40° to +120°C
- Environmental protection to IP68
- M12 connector for easy installation
- Mating cabled socket with 2m or 5m cable length
- Rapid availability
The SRH880P sensor operates from 9-30Vdc unregulated or 5Vdc regulated supply and is available with analog (0.5-4.5Vdc) or digital (PWM) output signals. The sensor is factory programmable, allowing you to specify the output signal type, the measurement range (0-20° to 0-360° in 1° increments) and the output direction (clockwise or anticlockwise).
The sensor has a 12-bit resolution (0.025%) over the selected measuring range, and operates from -40° to +120°C when powered at 5 or 9Vdc.
The Penny & Giles product range comprises a broad selection of joysticks, sensors and solenoids for use on commercial vehicles and industrial equipment.
The products are the legacy of the Penny & Giles company founded in 1956 and acquired by Curtiss Wright in 2002.
The present-day product range includes: linear and rotary position sensors; LVDT and RVDT transducers; joysticks; studio faders; digital panel meters; and solenoid actuators for a wide range of industrial motion control applications.
Their joystick controls are suitable for commercial vehicle applications for both on- and off-highway use. These include construction and agricultural vehicles, material handling and other specialty vehicles. They are also suitable for use with industrial equipment such as robotics. Their finger-operated joystick controllers are designed for the smooth, precise control of critical functions in a variety of industrial applications where a Human-Machine Interface (HMI) is required. They also have rugged joystick controllers are designed for the more demanding installations found within operator cabs for off-highway vehicles. A wide range of linear position sensors, tilt sensors, rotary sensors, linear displacement transducers and linear potentiometers that offer distinct advantages in reliability, stability and compactness.
