ND31LITE Power Network Meter

Lumel ND31LITE Power network meter with MODBUS RTU (RS485) protocol.

The ND31LITE network parameter meter, has been designed specifically for applications requiring high-quality measurement equipment that will provide the customer the ability to monitor network parameters via the popular and reliable RS485 interface with MODBUS protocol.



Description

Lumel ND31LITE Power network meter with MODBUS RTU (RS485) protocol.

The ND31LITE network parameter meter, has been designed specifically for applications requiring high-quality measurement equipment that will provide the customer the ability to monitor network parameters via the popular and reliable RS485 interface with MODBUS protocol.

Lumel are the producers of automation devices for measurement, control, transmission and visualisation of various industrial processes. They also provide Services of designing and manufacturing of automation systems.

Since 1954 Lumel brand has been known as a producer of quality measuring devices and high-pressure die-casting all over the world. Their high position in the market has been achieved thanks to continuous development, employees and modern technology in areas of research, design and production. Lumel delivers complex solutions for power and industrial automation sector as well as for automobile, chemical, steel, or HVAC industries.

Their objective is to provide comprehensive solutions by designing intelligent systems based on the electronics Lumel manufactures, which are measuring and regulating equipment for industrial, automotive and military applications, as well as through service production of electronics.

View more Lumel products.

Follow us on Facebook for updates.

• Measurement of 54 power network parameters, including current and voltage harmonics up to 63rd in 1-phase 2-wire or 3-phase 3 or 4-wire balanced and unbalanced systems.
• High accuracy class (0.2s for active energy)
• Graphical colour display: LCD TFT 3.5", 320 x 240 pixels, fully configurable by a user (10 screens, 8 parameters in each)
• Additional 2 screens for harmonics presentation and 1 dedicated screen for visualisation in the form of an analog meter
• Indications include the values of programmed ratios
• Memory of minimum and maximum values
• 2 configurable alarm outputs
• Supervisory relay mode for alarm outputs
• Programming of parameters using free eCon software
• Battery backup RTC
• Overall dimensions: 96 x 96 x 77mm
