Description
MAKERSAN MO 415 Inclination-Acceleration-Gyro Sensor is designed for safe, control applications, they are sealed and reliable sensors and covers a whole range from inclination, acceleration, position, pressure up to temperature.
- 6D IMU (3D Accelerometer + 3D Gyroscope) / Sensor Fusion
- Two axis: up to ±80°; One axis: ±180°
- ±2g, ±4g, ±8g, ±16g
- ±245dps, ±500dps, ±1000dps, ±2000dps
- Analogue type: M12 x 1 – 8 pin, CAN type: M12x1 – 5 pin
- Inclination: < ±0.5° (Ta = 23°C)
- Inclination: <0.01°, Acceleration: < 1mg, Gyro: <0.1 dps
- 40°C…+85°C
- Sealed to IP67
- Analogue + CAN type: 12-32V DC / CAN Type: 8-32V DC
- 0-5V Analogue Output (5mA), 2 Digital Outputs (500mA)
- 0.5V-4.5V Analogue Output (5mA), 2 Digital Outputs (500mA)
- Programmable switching points for digital outputs and measuring range for analogue outputs
- CAN type: SAE J1939 / CANopen
Makersan has been offering solutions to Mobile and Industrial Applications since 1978. They have ambitious goals, cooperates with universities and High Technology Institutes for the development and conception of new products which will comply with most advanced technology. They strive for research and development. They use their excessive resources and infrastructures for the pursuit of this challenge. Innovations are crowned by patent applications and Makersan has been awarded several times by applying and obtaining most of the patents among other SMEs by National and International Institutions. Their Head Quarters are Located at Gebze, Turkey’s one of the largest industrial zone with a close access to international sea and airports, grants accessibility and facilitates transportation.
Makersan has excellent capabilities of carrying out many complex mechanical and electronic manufacturing processes. Advanced pressing, joining, tooling, assembly, SMD mounting and soldering manufacturing lines are equipped with the high-tech industrial machinery. Our integrated manufacturing capability; designing, moulding, machining, pressing, plastic injection, programming, electronic assembly and validation testing are all accomplished at our factory. This is a strategical asset where Makersan’s agility and strength is derived from.
